Crop API

AI straightening, manual crop, pose crop, subject crop, and document portrait crop through the Retouch4me Cloud API.

Crop is a professional-mode plugin. It can return a flattened image, or it can write crop metadata into the ZIP result.json when Layer: 1 is used. Use this overview to choose the right Crop chapter for your integration.

Tilted source image for AI Straighten AI Straighten Use full-image AI straightening with maximum crop when the photo is tilted and needs a ready flattened JPEG. Ten fixed Pose Crop presets generated from one portrait source Pose Crop Use pose landmarks for person-aware automatic crop, fixed portrait presets, and face-based straightening. Subject mask overlay on a pear image Subject Crop and RLE Mask Use the detected subject mask for product or object crop, decode the RLE mask, and draw mask overlays. Document portrait crop example Passport and ID Photo Crop API Use a fixed 3:4 portrait crop for document photos, passport photos, ID photos, and profile-photo automation. Manual square crop example Manual Crop Playground Tune manual crop geometry visually and copy the generated User Params into your payload.

Mode Map

Workflow Main fields Detailed guide
AI straighten and maximum crop AutoStraightenMode: "AI", AutoMode: "Maximum" AI Straighten
Manual crop AutoStraightenMode: "Manual", ManualCenterX, ManualCenterY, ManualArea Manual playground
Pose/person crop AutoMode: "Auto" or "Fixed", AutoStraightenMode: "Person" Pose Crop
Subject crop AutoMode: "Subject", OnlyMainSubject, subjectMask Subject Crop and RLE Mask
Passport, ID, and document portrait crop AutoMode: "Fixed", CropModeIndex: 0, AspectRatio: "3 : 4" Passport and ID Photo Crop API

Common Parameters

Field Type Default Description
Plugin string required Use Crop.
Layer integer or boolean 0 0 returns a flattened image. 1 writes prediction metadata to ZIP result.json.
User Params.AutoMode string Manual Manual, Maximum, Auto, Fixed, or Subject.
User Params.AutoStraightenMode string Manual AI uses full-image tilt prediction. Person uses pose landmarks. Manual uses Angle.
User Params.AspectRatio string absent Accepted values include Free, Original, Custom, Square, 1 : 1, 2 : 3, 3 : 4, 4 : 5, and 16 : 9.
User Params.Extend number 0 Expands automatic, subject, or maximum crop framing.
User Params.FixSize / FixSizePixels boolean / integer false / 1000 When enabled, resizes the long side of the output to the requested pixel size.

Common API Flow

  1. Submit a multipart /retoucher/start request with file, token, and Crop payload.
  2. Poll /retoucher/status/{id} until state is completed.
  3. Download the result with /retoucher/getFile/{id}.

The Crop API uses the same authentication, polling, and file download flow as the rest of the Cloud Retouching API. See the main API documentation for endpoint details and error codes.
